16 AWG - 19x29 Stranded Tinned Copper

*Product images are for illustrative purposes only and may differ from the actual product.

16 AWG - 19x29 Stranded Tinned Copper

Download Spec Sheet

16 AWG - 19x29 Stranded Tinned Copper

Multi-Conductor - 80°C
Unshielded - 300 Volt / 600 Volt
PVC Insulation - PVC Jacket

x

Please select all above options before adding to cart.
Construction
Category Conductor Description Tinned Copper 2 & 3 conductors - 300 Volt 4+ conductors - 600 Volt
Category Insulation Description Polyvinyl Chloride (PVC)
Category Jacket Description Gray, Polyvinyl Chloride (PVC) over cabled conductors
  • Used for computers, communications, instrumentation, sound, control, audio, and data transmissions
  • Designed to protect signal integrity under critical conditions by reducing noise
  • UL Rated - 80°C
  • Suggested Working Voltage: 600 Volt

Questions & Answers

Ask a Question

Part Number Table

Part # Gauge Conductors Stranding Insulation Thickness Jacket Thickness Outside Diameter Inches Material Weight (Lbs./M')
D91602 16 2 19x29 TC 0.023 0.032 0.266 39
D91603 16 3 19x29 TC 0.023 0.032 0.283 52.4
D91604 16 4 19x29 TC 0.031 0.045 0.382 88
D91605 16 5 19x29 TC 0.031 0.045 0.417 109
D91607 16 7 19x29 TC 0.031 0.045 0.458 143
D91608 16 8 19x29 TC 0.031 0.045 0.496 170
D91609 16 9 19x29 TC 0.031 0.045 0.533 177
D91612 16 12 19x29 TC 0.031 0.06 0.627 251
D91615 16 15 19x29 TC 0.031 0.06 0.694 307
D91619 16 19 19x29 TC 0.031 0.065 0.74 363
D91625 16 25 19x29 TC 0.031 0.065 0.879 485

Note: The data shown is approximate and subject to standard industry and manufacturer tolerances. *Ring Band Striping
