Marine Cable 0M4 SGL JKT-LSZH, ABS #BELTM-4D9-012-LNAN

Zoom In Zoom Out Enlarge

*Product images are for illustrative purposes only and may differ from the actual product.

Download Spec Sheet

Brochure

Marine Cable 0M4 SGL JKT-LSZH, ABS

Part #: BELTM-4D9-012-LNAN

Qty *

x Length (ft) *

Please select all above options before adding to cart.

Construction Applications Standards Q&A

Construction
Sku	BELTM-4D9-012-LNAN
Category Features	• American Bureau of Shipping (ABS) Approved • Indoor/Outdoor Rated
Category Description	Marine Grade, Indoor/Outdoor, Distribution, OM4, 12 Fibers, Non-Unit 900um, Single Jacket - LSZH, OFNR-ST1, ABS Approved
Product Category	Fiber Distribution Cable
Max Operating Temperature	-40⁰C to +70⁰C
Fiber	OM4
Core	50/125 µm
Material	LSZH - Low Smoke Zero Halogen
Fiber Count	12
Color Coding	TIA-598-D
Strength Member	Waterblocking Aramid Yarns
Jacket Material	LSZH - Low Smoke Zero Halogen (Flame Retardant
Outer Jacket	0.310 (7.9)
Parts Table Footnote	To view a second manufacturer spec sheet copy and paste the following URL: https://www.omnicable.com/docs/default-source/default-document-library/beltm-4d9-012-lnan.pdf?sfvrsn=2

Extended Distance Horizontal & Backbone Data/Telco Network, Noisy Environment, Indoor/Outdoor & Wet Locations

IEEE 45 • ICEA S-104-696 • NEC/CEC OFCR-ST1/OFCR-ST1 FT4 • Flame Rating per UL 1666, 1685, IEEE 1202/FT4 • EU Directive 2015/863/EU • EU Directive 2011/65/EU (ROHS II) • ANSI/TIA-568.3-D, ANSI/TIA-598-D
