SRG-K

*Product images are for illustrative purposes only and may differ from the actual product.

SRG-K

Download Spec Sheet

SRG-K

SRG-K
200°C - 600 Volt

x

Please select all above options before adding to cart.
Construction
Category Conductor Description Annealed tinned copper
Category Insulation Description Silicone rubber, fiberglass braid
Category Jacket Description Aramid fiber braid
  • Used for leads to motors, transformers or other electrical equipment where hazardous and/or high temperature conditions exist requiring flexible heat resistant conductors at 600 volts
  • NEMA WC 3 Flame Propogation Test
  • IEEE 1202 Vertical Cable Tray Flame Test

Questions & Answers

Ask a Question

Part Number Table

Part # Gauge Conductors Stranding Kevlar Thickness Outside Diameter Inches Material Weight (Lbs./M')
C51403 14 3 7 .030" 0.4 75
C51404 14 4 7 .030" 0.435 100
C51405 14 5 7 .030" 0.48 125
C51407 14 7 7 .030" 0.52 170
C51203 12 3 19 .030" 0.43 110
C51204 12 4 19 .030" 0.475 145
C51205 12 5 19 .030" 0.52 175
C51207 12 7 19 .030" 0.57 240

Note: The data shown are approximate and subject to standard industry and manufacturer tolerances Stocked in K2/E2 color code with a black jacket. Other options available upon request
